CS-F24DD1E5, CS-F28DD1E5, CS-F34DD1E5, CS-F43DD1E5, CS-F50DD1E5
REF. NO. PARTS NAME Q’TY QUANTITY PER 1 UNIT
CS-F24DD1E5 CS-F28DD1E5 CS-F34DD1E5 CS-F43DD1E5 CS-F50DD1E5
1 Cabinet (Bottom) 1 P02-T08080 P02-T08130 P02-T08210 ← ←
2 Cabinet (Bottom A) 1 P02-T08090 P02-T08140 P02-T08420 ← ←
3 Drain pan 1 P42-T03850 P42-T03920 P42-T03930 ← ←
4 Evaporator 1 P45-T07860 P45-T07870 P45-T07890 ← ←
5 Distributor as. 1 P45-T07750 P45-T07790 P45-T07770 ← ←
6 Cabinet (Top) 1 P02-T07570 P02-T07490 ← ← ←
7 Cabinet (Back) 1 P42-T03380 P42-T03400 P42-T03390 ← ←
8 Duct flange as.(Outlet) 1 P42-T02390 P42-T02150 P42-T01860 ← ←
9 Fan base as. 1 P45-T07710 P45-T07720 P45-T07980 ← P45-T08020
10 Casing as. 2 *P45-T07950 *P45-T07990 ← ← P45-T07570
11 Impeller R 1 ---- ---- ---- ---- P05-T08780
12 Impeller L 1 ---- ---- ---- ---- P05-T08760
13 Fan motor 1 P06-T04910 P06-T04512 P06-T04920 ← P06-T05020
14 Panel side R as. 1 P42-T03860 P42-T03880 P42-T03940 ← ←
15 Panel side L as. 1 P42-T03870 P42-T03890 P42-T03960 ← ←
16 Terminal board 1 P06-T04970 ← ← ← ←
17 Capacitor 1 P06-T04360 ← P06-T04350 ← ←
18 Transformer 1 A40C1031 ← ← ← ←
19 Remote control 1 A75C2742 ← ← ← ←
20 Thermistor as. 1 P46-T06800 ← ← ← ←
21 Coil sensor 1 P46-T06790 ← ← ← ←
22 PCB assembly (Programed) 1 P46-T06870 P46-T06890 P46-T07040 P46-T07050 P46-T07060
23 FM Relay 3 ---- ---- ---- ---- P06-T03220
24 Fuse holder 1 ---- ---- ---- ---- P06-T04750
25 FM Fuse 1 ---- ---- ---- ---- P06-T04740
*Casing included with impeller part.
All parts are supplied from Taiwan (PTW).
138
