LG 52LB9RF [30/104] External equipment setup
![LG 52LB9RF [30/104] External equipment setup](/views2/1085644/page30/bg1e.png)
28
EXTERNAL EQUIPMENT SETUP
Resolution
720x400
640x480
800x600
1024x768
1280x768
1360x768
1280x1024
1400x1050
1600x1200
1920x1080
Supported Display Resolution (RGB[PC]/HDMI[PC]mode)
Horizontal Vertical
Frequency(kHz) Frequency(Hz)
31.5 70.1
31.5 59.9
37.9 60.3
48.4 60.0
47.8 59.9
47.7 59.8
63.7 59.5
65.3 60.0
75.0 60.0
66.6 60.0
NOTE
!
GG
To get the best picture quality, adjust the PC graphics card to 1920x1080, 60Hz.(60PC4R
*,
47LB9R
*
:
1360x768, 60Hz)
GG
Depending on the graphics card, DOS mode may not work if a HDMI to DVI Cable is in use.
GG
When Source Devices connected with HDMI Input, output TV SET Resolution
(
480p, 720p, 1080i) and
TV SET Display fit EIA/CEA-861-B Specification to Screen. If not, refer to the Manual of HDMI Source
Devices or contact your service center.
GG
If the HDMI Source Device is not connected to the Cable or if there is a poor cable connection, "No sig-
nal" is displayed in the HDMI Input. In this case, that Video Resolution is not supported.
GG
Avoid keeping a fixed image on the screen for prolonged periods of time. The fixed image may become
permanently imprinted on the screen.
GG
The synchronization input form for Horizontal and Vertical frequencies is separate.
GG
If you use too long an RGB-PC cable, there may be interference on the screen. We recommend using under
5m of the cable. This provides the best picture quality.
EXTERNAL EQUIPMENT SETUP
(Except 60PC4R*, 47LB9R*)
(60PC4R*, 47LB9R* only)
