PRODUCT SPECIFICATIONS
■
The specifications shown above may be changed without prior notice for quality improvement.
PAL/SECAM B/G/D/K, PAL I/II, NTSC-M
75 ohm
0 ~ 40°C / 32 ~ 104°F
Less than 80%
-20 ~ 60°C / -4 ~ 140°F
Less than 85%
Television System
External Antenna Impedance
Environment condition
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
1144.3 x 825.5 x 331.0 mm
45.1 x 32.5 x 13.0 inches
1144.3 x 754.7 x 103.0 mm
45.1 x 29.7 x 4.1 inches
37.6 kg / 82.9 lbs
31.5 kg / 69.4 lbs
AC100-240V~ 50/60Hz 3.2A
4477LLBB77RRFF
**
47LB7RF-TB
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
1033.4 x 750.0 x 287.6 mm
40.7 x 29.5 x 11.3 inches
1033.4 x 686.8 x 88.5 mm
40.7 x 27.0 x 3.5 inches
24.9 kg / 54.9 lbs
20.4 kg / 45.0 lbs
AC100-240V~ 50/60Hz 2.5A
4422LLBB77RRFF
**
42LB7RF-TB
1150 x 859 x 381 mm
45.3 x 33.8 x 15.0 inches
1150 x 768 x 103 mm
45.3 x 30.2 x 4.0 inches
38 kg / 83.8 lbs
32 kg / 70.5 lbs
AC100-240V~ 50/60Hz 3.0A
4477LLBB99RR
**
47LB9R-TD
47LB9R1-TB
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
5522LLBB99RRFF
**
52LB9RF-TD
52LB9RF1-TB
1289.0 x 950.0 x 421.0 mm
50.7 x 37.4 x 16.6 inches
1289.0 x 858.0 x 112.0 mm
50.7 x 33.8 x 4.4 inches
49.2 kg / 108.5 lbs
40.2 kg / 88.6 lbs
AC100-240V~ 50/60Hz 3.5A
