92
APPENDIX
APPENDIX
REMOTE CONTROL IR CODES
Code
Function Note
(Hexa)
Code
Function Note
(Hexa)
0B INPUT R/C Button
08 POWER R/C Button (Power On/Off)
43 MENU R/C Button
03 VOL
E
R/C Button
02 VOL
D
R/C Button
00 PR
D
R/C Button
01 PR
E
R/C Button
09 MUTE R/C Button
0E SLEEP R/C Button
10 ~ 19 Number Key 0 ~ 9 R/C Button
60 PIP R/C Button
61 PIP INPUT R/C Button
63 SWAP R/C Button
64 SIZE R/C Button
07
FF
R/C Button
06
GG
R/C Button
72 PIP PR- R/C Button
71 PIP PR+ R/C Button
5B EXIT R/C Button
62 POSITION R/C Button
79 RATIO R/C Button
40
DD
R/C Button
41
EE
R/C Button
1E FAV R/C Button
B0h R/C Button
B1h R/C Button
0A I/II R/C Button
B2h R/C Button
B3h R/C Button
0F TV R/C Button
BDh R/C Button
B4h R/C Button
B5h R/C Button
7E SIMPLINK R/C Button
20 TEXT R/C Button
53 LIST R/C Button
1A Q.VIEW R/C Button
70 INDEX R/C Button
26 TIME R/C Button
2A REVEAL R/C Button
65 HOLD R/C Button
BAh R/C Button
