87
APPENDIX
PRODUCT SPECIFICATIONS
■
The specifications shown above may be changed without prior notice for quality improvement.
PAL/SECAM B/G/D/K, PAL I/II, NTSC-M
75 ohm
0 ~ 40°C / 32 ~ 104°F
Less than 80%
-20 ~ 60°C / -4 ~ 140°F
Less than 85%
Television System
External Antenna Impedance
Environment condition
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
1613.6 x 1036.8 x 452 mm
63.5 x 40.8 x 17.8 inches
1613.6 x 970.0 x 118.5 mm
63.5 x 38.2 x 4.5 inches
82.6 kg / 182.0 lbs
66.6 kg / 146.8 lbs
AC100-240V~ 50/60Hz 6.5A
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
1236.9 x 795.6 x 325.6 mm
48.7 x 31.3 x 12.8 inches
1236.9 x 725.5 x 103.0 mm
48.7 x 28.6 x 4.1 inches
40.5 kg / 89.3 lbs
34.0 kg / 75.0 lbs
AC100-240V~ 50/60Hz 3.2A
4477LLYY33RRFF
**
47LY3RF-TB
1548 x 1061 x 448 mm
60.9 x 41.8 x 17.6 inches
1548 x 988 x 98.5 mm
60.9 x 38.9 x 3.9 inches
72.5 kg / 159.8 lbs
60 kg / 132.3 lbs
AC100-240V~ 50/60Hz 5.8A
6600PPCC44RR
**
60PC4R-TB
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
Dimensions
(Width x Height x Depth)
Weight
Power requirement
with stand
without stand
with stand
without stand
6600PPYY33RRFF
**
60PY3RF-TB
