LG 20LS1RH [55/59] Installation menu
![LG 20LS1RH [55/59] Installation menu](/views2/1085902/page55/bg37.png)
11
ENGLISH
Installation Menu
YYoouu ccaann aaddjjuusstt TTVVLLiinnkk--LLooaaddeerr mmeennuu bbyy oonnllyy TTVVLLiinnkk LLooaaddeerr wwhhiicchh iiss ttoo bbee
ppuurrcchhaasseedd aaddddiittiioonnaallllyy..
- TV sets for each single hotel rooms, providing ‘TVLink-Loader’ does maximise installers convenience. By
copying all programming settings, picture setting, sound setting and installation menu setting. from a set as
default and conveying into additional sets, which ensures uniformity between sets and significantly reduces
unnecessary installation time via RS232.
In addition to this, TVLink-Loader enables to load program for menu installation with wireless basis.
Press the
MMOODDEE
button until the display of TVLink Loader screen changes from “Ready” to “Mode in”.
• Be careful TVLink Loader doesn’t move and point the TVLink Loader towards the below center on the set
during this time.
Use the
UU PP
/
DDOOWWNN
button to select the TVLink Loader .
Press the
MMOODDEE
button in order to change from key to key and then press the
UU PP
button.
Press the
SSEENNDD
or
RREECCIIEEVVEE
button.
•
RREECCIIEEVVEE
:
RS232 is the main connection for receiving data.
•
SSEENNDD
:
For transmitting reserved data can be done by wireless IR Signal or RS232.
1. Press SEND button to select "IR Send"(to send data through IR)or "RS Send"(to send data
through RS232)for the download mode.
2. Press ENTER button to start transmitting.
The procedure of Loading will be projected on OSD.
Disappearing OSD implies Completion of data recieving or TV turns off automatically after completion of
data sending.
1
2
3
4
5
6
Ready to Download...
Downloading... 40
TVLink-Loader
Installation Menu V2.0
MCU Version 2.02
LG Hotel Mode Setup
GG
TV Link-Loader
GG
Password Change
GG
Set ID Setup
GG
Clock Setup
GG
Configuration Setup
GG
MENU
DE G
OK
