Zotek ZT-303 [11/27] Turn off the product at this position
![Zotek ZT-303 [11/27] Turn off the product at this position](/views2/1893228/page11/bgb.png)
Rotary Switch
Turn
off the product at this position.
•
The product automatically
powers
off after 15 minutes of inactivity.
•
The built-in beeper beeps 5
times
1 minute before auto power off.
•
To restart the product from
auto
power off, press the
SELECT
button or turn the rotary
switch
back to the OFF position and
then
to a needed position.
•
To disable the Auto Power
Off
function, hold down the
SELECT
button when turning on
the
product, you will hear five beeps
if
you have successfully
disabled
the function.
7
