5
Function Buttons
①
②
③ ④ ⑤
⑥
①
Push
once to hold the current reading on
the
display
; push again to continue
normal
operation
.
Push
for more than 2 seconds to turn on
the
backlight
; long-push again to turn off or
the
backlight
automatically turns off after
2
minutes
.
②
Selects alternate measurement modes on a
rotary switch setting, including:
1.
DC V/AC V
2.
DC mV/AC mV
3. Resistance/Continuity/Diode/Capacitance
4.
DC A/AC A
5.
DC mA/AC mA
6.
DC μA/AC μA
