88
DC voltage
≤1000V
AC voltage
≤750V
Press Hz % button at ACV setting:
Frequency with high voltage
Duty Cycle from 1%~99%
DC voltage ≤199.99mV
AC voltage ≤199.99mV
Ohms ≤200M
Ω
Continuity. Beeper turns on at
＜50Ω
Diode test. Displays above 3V
Farads
≤9.999mF
Frequency with low voltage
Duty Cycle from 1%~99%
DC A from ≤10.000A
AC A from ≤
10.000A
DC A from ≤199.99mA
AC A from ≤199.99m
A
DC A from ≤1999.9
μA
AC A from ≤1999.9
μA
Non
-contact voltage test.
