OMM-VTS-ver.6.3 (08.2022)
www.vtsgroup.us 13
4.3 Pre-Installation Checklist
Complete the following checklist before
beginning unit installation.
Verify the unit size and tagging with the
unit nameplate.
Make certain the floor or foundation is
level, solid, and sufficient to support the
unit and accessory weights. Refer to
device’s nameplate.
Level or repair the floor before
positioning the unit if necessary.
Allow minimum recommended
clearances for routine maintenance and
service. Refer to unit submittals for
dimensions.
Allow one and one half fan diameters
above the unit for the discharge
ductwork.
