OMM-VTS-ver.6.3 (08.2022)
www.vtsgroup.us 16
5.2 Horizontal AHU with Heat Wheel and Cross-Flow
Exchanger
Table 6 Basic dimensions of horizontal AHUs with energy recovery system
Size
W
H2
H
Wi
Hi
Hf
[in]
AVS 8*
27,95
40,39
21,97
24,02
14,49
3,54
AVS 12
38,62
40,39
21,97
34,69
14,49
3,54
AVS 16
44,21
44,49
24,02
40,28
16,54
3,54
AVS 20
46,77
50,79
27,17
42,83
19,69
3,54
AVS 30
53,50
61,42
32,48
49,57
25,00
3,54
AVS 40
59,06
70,87
37,20
55,12
29,72
3,54
AVS 55
66,14
78,74
41,14
62,20
33,66
3,54
AVS 65
75,24
81,65
42,60
71,30
35,12
3,54
AVS 85
82,87
89,61
46,57
78,94
39,09
3,54
AVS 100
82,87
107,64
54,21
78,94
47,13
3,15
AVS 130
98,94
107,64
54,21
95,00
47,13
3,15
AVS 170
102,56
131,18
65,98
98,62
58,90
3,15
AVS 230
122,24
149,53
75,16
118,31
68,07
3,15
AVS 300
141,93
149,53
75,16
137,99
68,07
3,15
AVS 380
146,34
187,09
93,94
142,40
86,85
3,15
* for unit AVS 8 Heat Wheel is not available
Fig. 9 Horizontal AHUs with energy recovery
system – AVS 8 - 85
Fig. 10 Horizontal AHUs with energy recovery
system – AVS 100 - 380
