OMM-VTS-ver.6.3 (08.2022)
www.vtsgroup.us 14
5 Dimensions and Weights
Data of weights is given in the AHU nameplate and technical data that is available in the VTS selection
software.
5.1 Horizontal AHU
Table 4 Basic dimensions of horizontal AHUs
Size
W
H
Wi
Hi
Hf
[in]
AVS 8*
28
22
24
14,5
3,54
AVS 12
38,6
22
34,7
14,5
3,54
AVS 16
44,2
24
40,3
16,5
3,54
AVS 20
46,8
27,2
42,8
19,7
3,54
AVS 30
53,5
32,5
49,6
25
3,54
AVS 40
59,1
37,2
55,1
29,7
3,54
AVS 55
66,1
41,1
62,2
33,7
3,54
AVS 65
75,2
42,6
71,3
35,1
3,54
AVS 85
82,9
46,6
78,9
39,1
3,54
AVS 100
82,9
54,2
78,9
47,1
3,15
AVS 130
98,9
54,2
95
47,1
3,15
AVS 170
102,6
66
98,6
58,9
3,15
AVS 230
122,2
75,2
118,3
68,1
3,15
AVS 300
141,9
75,2
138
68,1
3,15
AVS 380
146,3
93,9
142,4
86,9
3,15
Fig. 6 Horizontal units AVS 8-85
Fig. 7 Horizontal units AVS 100-380
The length “L” of the units depends on the used function and is shown in nameplate and technical data
available in the VTS selection software.
