6 Installation of Variable Frequency Drive (Frequency
Converter)
A variable frequency drive is an integral part of
each fan section. It is factory mounted and
comes as a standard equipment of the air
handling unit. Before beginning installation,
follow the wiring instructions given in this
document. Especially, refer to the unit wiring
schematic for specific wiring details (see the
section 7 in this document).
Notes on Installation
Avoid placing VFD devices in the area, which
is subject to the following conditions:
Radiant heat from the sun, fireplaces,
other appliances, etc.
Direct sunlight exposure.
Fog, fumes, oil mist or other exhaust
from kitchen appliances or industrial
processes.
Dripping water from humidity
condensation or any other source.
