Table 8 Dimensions of hydronic coil exchangers of AVS 8-170 (Fig. 12)
Coil code
LD
HR
C
HC
TR
OD
d
[in]
AVS 8 WCL1
23,70
12,64
2,36
5,91
4,33
3/4"
1/4"
AVS 8 WCL 2
23,70
12,64
2,36
5,91
4,33
3/4"
1/4"
AVS 8 WCL 3
23,70
12,64
3,25
5,91
5,71
3/4"
1/4"
AVS 8 WCL 4
23,70
12,64
3,25
5,91
5,71
3/4"
1/4"
AVS 8 WCL 6
23,70
12,64
5,41
5,91
7,48
3/4"
1/4"
AVS 8 WCL 8
23,70
12,64
7,58
5,91
9,84
3/4"
1/4"
AVS 12 WCL 1
34,37
12,64
2,28
5,91
4,33
1"
1/4"
AVS 12 WCL 2
34,37
12,64
2,28
5,91
4,33
1"
1/4"
AVS 12 WCL 3
34,37
12,64
3,25
5,91
5,71
1"
1/4"
AVS 12 WCL 4
34,37
12,64
3,25
5,91
5,71
1"
1/4"
AVS 12 WCL 6
34,37
12,64
5,41
5,91
7,48
1"
1/4"
AVS 12 WCL 8
34,37
12,64
7,58
5,91
9,84
1"
1/4"
AVS 20 WCL 1
42,52
17,64
2,28
5,91
4,33
1"
1/4"
AVS 20 WCL 2
42,52
17,64
2,28
5,91
4,33
1"
1/4"
AVS 20 WCL 3
42,52
17,64
3,25
5,91
5,71
1"
1/4"
AVS 20 WCL 4
42,52
17,64
3,25
5,91
5,71
1"
1/4"
AVS 20 WCL 6
42,52
17,64
5,41
5,91
8,46
11/4"
1/4"
AVS 20 WCL 8
42,52
17,64
7,58
5,91
9,84
11/4"
1/4"
AVS 40 WCL 1
54,8
27,6
2
10,2
4,4
1 1/4"
1/4"
AVS 40 WCL 2
54,8
27,6
2
10,2
4,4
1 1/4"
1/4"
AVS 40 WCL 3
54,8
27,6
3,2
10,2
5,8
1 1/4"
1/4"
AVS 40 WCL 4
54,8
27,6
3,2
10,2
5,8
1 1/4"
1/4"
AVS 40 WCL 6
54,8
27,6
3,2
10,2
7,2
2"
1/4"
AVS 40 WCL 8
54,8
27,6
5,4
10,2
11,3
2"
1/4"
AVS 55 WCL 1
61,9
31,7
2
10,2
4,4
1 1/4"
1/4"
AVS 55 WCL 2
61,9
31,7
2
10,2
4,4
1 1/4"
1/4"
AVS 55 WCL 3
61,9
31,7
3,2
10,2
7,2
2"
1/4"
AVS 55 WCL 4
61,9
31,7
3,2
10,2
7,2
2"
1/4"
AVS 55 WCL 6
61,9
31,7
5,4
10,2
8,5
2"
1/4"
AVS 55 WCL 8
61,9
31,7
5,4
10,2
11,3
3"
1/4"
AVS 65 WCL 1
70,9
33
2
10,2
4,4
1 1/4"
1/4"
AVS 65 WCL 2
70,9
33
2
10,2
4,4
1 1/4"
1/4"
AVS 65 WCL 3
70,9
33
3,2
10,2
7,2
2"
1/4"
AVS 65 WCL 4
70,9
33
3,2
10,2
7,2
2"
1/4"
AVS 65 WCL 6
70,9
33
5,4
10,2
9,9
3"
1/4"
AVS 65 WCL 8
70,9
33
5,4
10,2
11,3
3"
1/4"
AVS 85 WCL 1
78,6
36,9
2
10,2
4,4
1 1/4"
1/4"
AVS 85 WCL 2
78,6
36,9
2
10,2
4,4
1 1/4"
1/4"
AVS 85 WCL 3
78,6
36,9
3,2
10,2
7,2
2"
1/4"
AVS 85 WCL 4
78,6
36,9
3,2
10,2
7,2
2"
1/4"
AVS 85 WCL 6
78,6
36,9
5,4
10,2
9,9
3"
1/4"
AVS 85 WCL 8
78,6
36,9
5,4
10,2
11,3
3"
1/4"
AVS 100 WCL 1
78,6
44,8
3,2
10,2
6,6
2"
1/4"
AVS 100 WCL 2
78,6
44,8
3,2
10,2
8,6
2"
1/4"
AVS 100 WCL 3
78,6
44,8
3,9
10,2
8,6
3"
1/4"
AVS 100 WCL 4
78,6
44,8
3,9
10,2
8,6
3"
1/4"
AVS 100 WCL 6
78,6
44,8
5,4
10,2
10
3"
1/4"
AVS 100 WCL 8
78,6
44,8
5,4
10,2
11,3
2x3"
1/4"
AVS 130 WCL 1
94,7
44,8
3,9
10,2
8,6
2"
1/4"
AVS 130 WCL 2
94,7
44,8
3,9
10,2
8,6
3"
1/4"
AVS 130 WCL 3
94,7
44,8
3,9
10,2
8,6
3"
1/4"
AVS 130 WCL 4
94,7
44,8
3,9
10,2
8,6
3"
1/4"
AVS 130 WCL 6
94,7
44,8
5,4
10,2
10
3"
1/4"
AVS 130 WCL 8
94,7
44,8
5,4
10,2
11,3
2x3"
1/4"
AVS 170 WCL 1
98,3
56,7
3,9
10,2
8,6
3"
1/4"
AVS 170 WCL 2
98,3
56,7
3,9
10,2
8,6
3"
1/4"
AVS 170 WCL 3
98,3
56,7
3,9
10,2
8,6
3"
1/4"
AVS 170 WCL 4
98,3
56,7
3,9
10,2
8,6
3"
1/4"
AVS 170 WCL 6
98,3
56,7
5,4
10,2
10
3"
1/4"
AVS 170 WCL 8
98,3
56,7
5,4
10,2
11,3
2x3"
1/4"
