Asus TUF GAMING Z790-PLUS D4 [17/70] Chapter 1

TUF GAMING Z790-PLUS D4

1-7

Chapter 1

3. Expansion slots

Unplug the power cord before adding or removing expansion cards. Failure to do so may

cause you physical injury and damage motherboard components.

PCIEX1(G3)_2

PCIEX4(G4)

PCIEX1(G3)_1

PCIEX16(G4)

PCIEX16
