Chapter 1: Product Introduction

Chapter 1

14. COM Port header

The COM (Serial) Port header allows you to connect a COM port module. Connect the

COM port module cable to this header, then install the module to a slot opening on the

system chassis.

COM

PIN 1

DCD

TXD

GND

RTS

RXD

DTR

DSR

CTS

The COM port module is purchased separately.
