Asus TUF GAMING Z790-PLUS D4 [53/70] Chapter 2

TUF GAMING Z790-PLUS D4

2-21

Chapter 2

** Audio 2, 4, 5.1 or 7.1-channel configuration

Port 2-channel 4-channel 5.1-channel 7.1-channel

Light Blue

(Rear panel)

– – – Side Speaker

Out

Lime

(Rear panel)

Front Speaker

Out

Front Speaker

Out

Front Speaker

Out

Front Speaker

Out

Pink

(Rear panel)

– – – –

Black

(Rear panel)

– Rear Speaker

Out

Rear Speaker

Out

Rear Speaker

Out

Orange

(Rear panel)

– – Center/

Subwoofer

Center/

Subwoofer

ACT/LINK

LED

SPEED

LED

LAN port

* Intel

2.5Gb Ethernet port LED indications

Activity Link LED

Status Description

OFF

No link

GREEN

Linked

BLINKING

Data activity

Speed LED

Status Description

OFF No link

OFF

100 Mbps / 10 Mbps

connection

GREEN 2.5 Gbps connection

ORANGE 1 Gbps connection
