Asus TUF GAMING Z790-PLUS D4 [37/70] Chapter 2

TUF GAMING Z790-PLUS D4

2-5

Chapter 2

To install an AIO cooler

AIO_PUMP

CPU_OPT

CPU_FAN

• We recommend using a LGA1700 compatible cooling system when installing a

cooling system to an Intel

700 and 600 series motherboard.

• An additional hole for LGA1200 compatible cooling systems is also available on

ASUS’ Intel

700 and 600 series motherboards, however, we still strongly advise

consulting with your cooling system vendor or manufacturer on the compatibility and

functionality of the cooling system.

• If you wish to install an AIO cooler, we recommend installing the AIO cooler after

installing the motherboard into the chassis.
