Asus ROG STRIX Z690-G GAMING WIFI [12/94] Qfan control

ROG STRIX Z690 SERIES BIOS Manual

2.3 Qfan Control

The Qfan Control allows you to set a fan profile or manually configure the operating speed of

your CPU and chassis fans.

Click to select a fan to be

configured

Click to activate PWM Mode

Click to undo the

changes

Click to apply the fan setting

Click to go back to main menu

Select a profile to

apply to your fans

Click to activate DC Mode

Select to manually configure

your fans
