90
ROG STRIX Z690 SERIES BIOS Manual
9.7 MyASUS
This item allows you to enable or disable downloading and installing of the MyASUS app in
the Windows
®
OS.
The availability of this menu, as well as the settings and options may vary depending on
your motherboard. Please refer to the BIOS of your motherboard for the actual settings
and options.
Download & Install MyASUS service & app
Configuration options: [Disabled] [Enabled]
9.6 ASUS Armoury Crate
This item allows you to enable or disable downloading and installing of the Armoury Crate
app in the Windows
®
OS. The Armoury Crate app can help you manage and download the
latest ROG drivers and utilities for your motherboard.
Download & Install ARMOURY CRATE app
Configuration options: [Disabled] [Enabled]
