ROG STRIX Z690 SERIES BIOS Manual
57
DVMT Pre-Allocated
Allows you to select the DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used
by the Internal Graphics Device.
Configuration options: [32M] [64M] [96M] [128M] [160M] [192M] [224M] [256M] [288M]
[320M] [352M] [384M] [416M] [448M] [480M] [512M]
RC6(Render Standby)
Allows you to enable render standby support.
Configuration options: [Disabled] [Enabled]
VMD setup menu
The items in this submenu allow you to set the VMD configuration settings.
Enable VMD controller
Allows you to enable or disable the VMD controller.
Configuration options: [Disabled] [Enabled]
Setting the Enable VMD controller to [Disabled] may result in data loss.
The following items appear only when Enable VMD controller is set to [Enabled].
Map PCIE Storage under VMD
Allows you to map or unmap PCIE Storage to VMD.
Configuration options: [Disabled] [Enabled]
Ensure to set Map SATA Controller under VMD to [Disabled] if you set Map PCIE
Storage under VMD to [Enabled].
Map SATA Controller under VMD
Allows you to map or unmap this Root Port to VMD.
Configuration options: [Disabled] [Enabled]
Ensure to set Map PCIE Storage under VMD to [Disabled] if you set Map SATA
Controller under VMD to [Enabled].
PCI Express Configuration
The items in this submenu allow you to configure the PCIe Speeds for the different onboard
slots.
The items in this submenu may vary according to your motherboard. Please refer to the
BIOS of your motherboard for the actual settings and options.
M.2_2 Link Speed
Allows you to configure the M.2_2 slot.
Configuration options: [Auto] [Gen1] [Gen2] [Gen3] [Gen4]
PCIEX16(G5)
Allows you to configure the PCIEX16(G5) slot.
Configuration options: [Auto] [Gen1] [Gen2] [Gen3] [Gen4] [Gen5]
