42
ROG STRIX Z690 SERIES BIOS Manual
PLL Termination Voltage
Allows you to configure the voltage for the PLL Termination. Use the <+> and <->
keys to adjust the value. The values range from 0.800V to 1.800V with an interval of
0.010V.
Configuration options: [Auto] [0.80000V] - [1.80000V]
CPU Standby Voltage
Allows you to configure the voltage for the CPU Standby. Use the <+> and <-> keys to
adjust the value. The values range from 0.800V to 1.800V with an interval of 0.010V.
Configuration options: [Auto] [0.80000] - [1.80000]
PCH 1.05V Voltage
Allows you to configure the voltage for the PCH 1.05V. Use the <+> and <-> keys to
adjust the value. The values range from 0.800V to 1.600V with an interval of 0.010V.
Configuration options: [Auto] [0.80000] - [1.60000]
PCH 0.82V Voltage
Allows you to configure the voltage for the PCH 0.82V. The values range from 0.700V
to 1.300V with an interval of 0.010V.
Configuration options: [Auto] [0.70000] - [1.30000]
CPU Input Voltage Reset Voltage
Allows you to configure the voltage for the CPU Input when reset. Use the <+> and
<-> keys to adjust the value. The values range from 1.500V to 2.100V with an interval
of 0.010V.
Configuration options: [Auto] [1.50000] - [2.10000]
AI Features
The items in this menu allows you to enable or disable different AI Features.
Package Temperature Threshold
Frequency will adjust to stay below this package temperature threshold when
regulation is enabled.
Configuration options: [Auto] [30] - [115]
Regulate Frequency by above Threshold
Frequency will adjust to stay below the Package Temperature Threshold when this
item is enabled. SVID must be enabled for this to work.
Configuration options: [Auto] [Enabled] [Disabled]
Cooler Efficiency Customize
[Keep Training] Continuous evaluations will be performed on Cooler efficiency
and updated accordingly.
[Stop Training] Cooler efficiency evaluations will stop and current evaluated
efficiency will be used.
[User Specify] Manually specify the Cooler efficiency and all predictions will be
based off this manual setting.
The following item appears only when Cooler Efficiency Customize is set to [User
Specify].
Cooler Score
The value of the Cooler’s pts. [Maximum] 250 pts; [Minimum] 1 pts; [Default] 125 pts.
Configuration options: [1] - [250]
