ROG STRIX Z690 SERIES BIOS Manual
CPU Core/Cache Voltage
Configures the mode of Voltage fed to the CPU cores. Manual mode allows user-defined
values. Offset mode modifies values by SVID.
Configuration options: [Auto] [Manual Mode] [Offset Mode]
The following item appears only when CPU Core/Cache Voltage is set to [Manual
Mode].
CPU Core Voltage Override
Allows you to configure the input voltage for the CPU by the external voltage regulator. Use
the <+> and <-> keys to adjust the value. The values range from 0.600V to 1.700V with an
interval of 0.005V.
Configuration options: [Auto] [0.60000] - [1.70000]
The following items appears only when CPU Core/Cache Voltage is set to [Offset Mode].
Offset Mode Sign
[+] To offset the CPU core voltage by a positive value.
[–] To offset the CPU core voltage by a negative value.
CPU Core Voltage Offset
Allows you to configure the input voltage for the CPU by the external voltage regulator. Use
the <+> or <-> to adjust the value. The values range from 0.005V to 0.635V with an interval
of 0.005V.
Configuration options: [Auto] [0.00500] - [0.63500]
CPU Graphics Voltage
Allows you to configure the mode of voltage fed to the CPU Graphics. Manual mode allows
user-defined values. Offset mode modified values by SVID.
Configuration options: [Auto] [Manual Mode] [Offset Mode] [Adaptive Mode]
The following item appears only when CPU Graphics Voltage is set to [Manual Mode].
CPU Core Voltage Override
Allows you to configure the input voltage for the CPU by the external voltage regulator. Use
the <+> and <-> keys to adjust the value. The values range from 0.600V to 1.700V with an
interval of 0.005V.
Configuration options: [Auto] [0.60000] - [1.70000]
The following item appears only when CPU Core/Cache Voltage is set to [Offset Mode],
or [Adaptive Mode].
Offset Mode Sign
[+] To offset the CPU core voltage by a positive value.
[–] To offset the CPU core voltage by a negative value.
