ROG STRIX Z690 SERIES BIOS Manual
51
6.1 Platform Misc Configuration
The items in this menu allow you to configure the platform-related features. Scroll down to
display other BIOS items.
PCI Express Native Power Management
Allows you to enhance the power saving feature of PCI Express and perform ASPM
operations in the operating system.
Configuration options: [Disabled] [Enabled]
The following item appears only when PCI Express Native Power Management is set to
[Enabled].
Native ASPM
Set this item to [Enabled] for OS Controlled ASPM, or set this item to [Disabled] for BIOS
controlled ASPM.
Configuration options: [Auto] [Enabled] [Disabled]
PCH - PCI Express
DMI Link ASPM Control
Allows you to control the Active State Power Management of the DMI Link.
Configuration options: [Disabled] [L1] [Auto]
ASPM
Allows you to select the ASPM state for energy-saving conditions.
Configuration options: [Disabled] [L1] [Auto]
L1 Substates
Allows you to select the PCI Express L1 Substates settings.
Configuration options: [Disabled] [L1.1] [L1.1 & L1.2]
