ROG STRIX Z690 SERIES BIOS Manual
37
Auto Voltage Caps
CPU Core Auto Voltage Cap
Setting this to a specific value will set a ceiling for CPU Core Auto Voltage. When not
in manual mode, it’s effectiveness is subject to other factors such as AC/DC Loadline
values and CPU’s native VID.
Configuration options: [Auto] [0.60000] - [1.70000]
CPU Input Auto Voltage Cap
Setting this to a specific value will set a ceiling for CPU Input Auto Voltage.
Configuration options: [Auto] [1.50000] - [2.10000]
Memory Controller Auto Voltage Cap
Setting this to a specific value will set a ceiling for Memory Controller Auto Voltage.
Configuration options: [Auto] [1.00000] - [2.00000]
Internal CPU Power Management
The items in this submenu allow you to set the CPU ratio and features.
Maximum CPU Core Temperature
Set the maximum allowable temperature for CPU cores. The CPU will throttle or
shutdown when it reaches this temperature to prevent damaging the cores.
Configuration options: [Auto] [62] - [115]
Do not set this value too high, as high temperatures may damage the CPU permanently.
TCC Activation Offset
Offset from factory set TCC activation temperature at which the Thermal Control
Circuit must be activated. Tcc will be activated at: TCC Activation Temp - Tcc
Activation Offset.
Configuration options: [Auto] [1] - [63]
Package Temperature Threshold
When regulation is set to enable, frequency will adjust to stay below this package
temperature threshold.
Configuration options: [Auto] [30] - [115]
Regulate Frequency by above Threshold
When regulation is set to enable, frequency will adjust to stay below the above
threshold. SVID must be enabled for this to work.
Configuration options: [Auto] [Enabled] [Disabled]
Turbo Mode Parameters
IVR Transmitter VDDQ ICCMAX
Configuration options: [Auto] [0] - [15]
CPU Core/Cache Current Limit Max.
Allows you to configure a current limit for frequency or power throttling when
overclocking. Can be set to maximum value (511.75) to prevent throttling when
overclocking.
Configuration options: [Auto] [0.00] - [511.75]
