60
ROG STRIX Z690 SERIES BIOS Manual
SATA6G_1 - SATA6G_4
Allows you to enable or disable the selected SATA port.
Configuration options: [Disabled] [Enabled]
SATA6G_1 - SATA6G_4 Hot Plug
Designates this port as Hot Pluggable.
Configuration options: [Disabled] [Enabled]
6.6 PCH-FW Configuration
This item allows you to configure the firmware TPM.
PTT
Allows you to enable or disable PTT in SkuMgr.
Configuration options: [Disabled] [Enabled]
6.7 Thunderbolt(TM) Configuration
The items in this menu allow you to configure Thunderbolt settings.
The availability of this menu, as well as the settings and options may vary depending on
your motherboard. Please refer to the BIOS of your motherboard for the actual settings
and options.
PCIE Tunneling over USB4
Allows you to enable or disable PCIE Tunneling over USB4.
Configuration options: [Disabled] [Enabled]
