1.1.6 Onboard LEDs

1. Q LEDs (BOOT_LED, VGA_LED, DRAM_LED, CPU_LED)

QLEDscheckkeycomponents(CPU,DRAM,VGAcard,andbootingdevices)in

sequenceduringmotherboardbootingprocess.Ifanerrorisfound,thecorresponding

LEDremainslituntiltheproblemissolved.Thisuser-friendlydesignprovidesan

intuitivewaytolocatetherootproblemwithinseconds.

TUF GAMING X570-PLUS (WI-FI)

CPU/ DRAM/ BOOT_DEVICE/ VGA LED

CPU (RED)

DRAM (YELLOW)

VGA (WHITE)

BOOT (YELLOW GREEN)

TheQLEDsprovidethemostprobablecauseofanerrorcodeasastartingpointfor

troubleshooting.Theactualcausemayvaryfromcasetocase.
