Asus TUF GAMING X570-PLUS (WI-FI) [40/79] Chapter 2

2-8

Chapter 2: Basic Installation

Chapter 2

2.1.7 Front I/O connector

To install the front panel connector

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.2 Gen 1

To install USB 3.2 Gen 1 connector
