Asus TUF GAMING X570-PLUS (WI-FI) [47/79] Chapter 2

ASUS TUF GAMING X570-PLUS (WI-FI)

2-15

Chapter 2

Connect to 5.1 channel Speakers

Use only the light blue audio port for Side Speaker Out in a 5.1 channel conguration.

Connect to 7.1 channel Speakers
