Asus TUF GAMING X570-PLUS (WI-FI) [24/79] Front panel audio connector 10 1 pin aafp

1-10

Chapter 1: Product Introduction

Chapter 1

1. Front panel audio connector (10-1 pin AAFP)

Thisconnectorisforachassis-mountedfrontpanelaudioI/OmodulethatsupportsHD

Audio.ConnectoneendofthefrontpanelaudioI/Omodulecabletothisconnector.

Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis

connectortoavailofthemotherboard’shigh-denitionaudiocapability.

1.1.8 Internal connectors

TUF GAMING X570-PLUS (WI-FI) Front panel connector

AAFP

AGND

SENSE1_RETUR

SENSE2_RETUR

PORT1 L

PORT1 R

PORT2 R

SENSE_SEND

PORT2 L

HD-audio-compliant

pin definition

2. SPI_TPM connector (14-1 pin SPI_TPM)

ThisconnectorsupportsaTrustedPlatformModule(TPM)systemwithaSerial

PeripheralInterface(SPI),allowingyoutosecurelystorekeys,digitalcerticates,

passwordsanddata.ATPMsystemalsoenhancesnetworksecurity,protectsdigital

identities,andensuresplatformintegrity.

TheSPI_TPMmoduleispurchasedseparately.

TUF GAMING X570-PLUS (WI-FI) SPI_TPM connector

PIN 1

+1.8V TPM

PLTRST#

+18V SPI

SPI CS#

SPI MISO

SPI HOLD#

SPI TPM IRQ#

SPI TPM CS#

SPI FLASH WP#

GND

SPI CLK

SPI MOSI

SPI_TPM
