10. M.2 sockets (M.2_1; M.2_2)

ThesesocketsallowyoutoinstallM.2SSDmodules.

• ForAMDRyzen™3

GenerationProcessors,theM.2_1socketsupportsPCIe4.0

x4modeandSATAmodeMKeydesignandtype2242/2260/2280/22110storage

devices.

• ForAMDRyzen™2

Generation/Ryzen™2

nd

and



st

GenerationwithRadeon™

VegaGraphicsProcessors,theM.2_1socketsupportsPCIe3.0x4modeandSATA

modeMKeydesignandtype2242/2260/2280/22110storagedevices.

• TheM.2_2socketsupportsPCIe4.0x4modeandSATAmodeMKeydesignand

type2242/2260/2280/22110storagedevices.

TheM.2SSDmoduleispurchasedseparately.

TUF GAMING X570-PLUS (WI-FI) M.2 sockets

228022110 2260 2242

M.2_2(SOCKET3)

M.2_1(SOCKET3)
