Инструкция по эксплуатации Страница: 38

Asus TUF GAMING X570-PLUS (WI-FI) [38/79] Chapter 2

2-6

Chapter 2: Basic Installation

Chapter 2

2.1.4 DIMM installation

To remove a DIMM
