ix
(continued on the next page)
Wireless Data Network
- Intel
®
Wireless-AC 9260
- 2x2 Wi-Fi 5(802.11 a/b/g/n/ac) with MU-MIMO support dual
frequency band 2.4/5 GHz
- Supports channel bandwidth: HT20/HT40/HT80/HT160
Bluetooth
Bluetooth
®
5.0
Storage
AMD Ryzen™ 3
rd
Generation Processors
- 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110
storage devices support (SATA & PCIE 4.0 x 4 mode)
AMD Ryzen™ 2
nd
Generation / Ryzen™ 2
nd
and 1
st
Generation
with Radeon™ Vega Graphics Processors
- 1 x M.2_1 socket 3 with M key, type 2242/2260/2280/ 22110
storage devices support (SATA & PCIE 3.0 x 4 mode)
AMD X570 Chipset:
- 1 x M.2_2 socket 3 with M key, type 2242/2260/2280/22110
storage devices support (SATA & PCIE 4.0 x 4 mode)
- 8 x SATA 6Gb/s ports
- Supports Raid 0, 1, 10
Audio
Realtek
®
S1200A 8-channel High Denition Audio CODEC
- Exclusive DTS Custom for GAMING Headsets
- Audio Shielding: Ensures precision analog/digital separation and
greatly reduces multi-lateral interference
- Dedicated audio PCB layers: Separate layers for left and right
channels to guard the quality of the sensitive audio signals
- Premium Japanese audio capacitors: Provide warm, natural and
immersive sound with exceptional clarity and delity
- Supports jack-detection and front panel jack-retasking
- Audio Cover: Effective shielding preserves the integrity of audio
signals to ensure best quality
USB
- 3 x USB 3.2 Gen 2 (up to 10Gbps) ports at back panel (2 x Type-A
ports; 1 x Type-C port)
- 6 x USB 3.1 Gen 1 ports at mid-board (2 ports at mid-board, 4
ports at back panel)
- 4 x USB 2.0 ports at mid-board
ASUS Unique Features
ASUS TUF PROTECTION
- ASUS SafeSlot - Protect your graphics card Investment
- ASUS ESD Guard: Enhanced ESD protection
- ASUS LANGuard: Protects against LAN surges, lightning
strikes and static-electricity discharges!
- ASUS Overvoltage Protection: World-class circuit-protecting
power design
- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for
greater durability!
- ASUS DIGI+ VRM
TUF ENGINE! Power Design
- TUF Components (Choke, Cap. ; certied by military-standard)
TUF GAMING X570-PLUS (WI-FI) specications summary
