Asus TUF GAMING X570-PLUS (WI-FI) [34/79] Chapter 2

2-2

Chapter 2: Basic Installation

Chapter 2

3. Place nine (9) screws into the holes indicated by circles to secure the motherboard to

the chassis.

DO NOT over tighten the screws! Doing so can damage the motherboard.
