Asus ROG Zenith II Extreme [15/112] The tools and components in the table above are not included in the motherboard package

Installation tools and components

1 Bag of screws Screwdriver

PC chassis Power supply unit

AMD Socket sTRX4 CPU AMD Socket sTRX4 compatible CPU Fan

DDR4 DIMM SATA hard disk drive

SATA optical disc drive (optional) Graphics card (optional)

The tools and components in the table above are not included in the motherboard

package.
