Asus ROG Zenith II Extreme [57/112] Front i o connector

ROG ZENITH II EXTREME

2-9

Chapter 2

2.1.7 Front I/O connector

To install USB 3.2 Gen 2 connectorTo install ASUS Q-Connector

This connector will only fit in one

orientation. Push the connector until it

clicks into place.

USB 2.0

AAFP

To install USB 2.0 connector

To install front panel audio connector

USB 3.2 Gen 1

To install USB 3.2 Gen 1 connector

To install system speaker connector

USB 3.2 Gen 2
