Asus ROG Zenith II Extreme [32/112] Chapter 1

1-16

Chapter 1: Product Introduction

Chapter 1

3. BIOS LED

The BIOS LEDs indicate which BIOS chip is currently in use.

4. 8-pin Power Plug LED

The 8-pin Power Plug LED lights up to indicate that the 8-pin power plug is not

connected.

• DO NOT connect the 8-pin power plug only, the motherboard may overheat under

heavy usage.

• Due to the CPU minimum power consumption requirement, we recommend using a

PSU with 850W or above. Ensure to connect both the 8-pin and 4-pin power plugs

(into another 8-pin connector), or two 8-pin power plugs or above to ensure system

stability under heavy loading.
