Asus ROG Zenith II Extreme [24/112] Chapter 1

1-8

Chapter 1: Product Introduction

Chapter 1

• We recommend that you provide sufficient power when running CrossFireX™ or SLI

mode.

• Ensure to connect the 8-pin and 6-pin power plugs when running CrossFireX™ or

SLI

mode.

• Connect a chassis fan to the chassis fan connectors when using multiple graphics

cards for better thermal environment.

Recommended VGA configuration

3rd Gen AMD Ryzen™ Threadripper™ Desktop Processors

Slot Description Single VGA SLI

/CFX 3-Way SLI

/CFX

1. PCIe 4.0 x16_1 x16 x16 x16

PCIe 4.0 x16_2

- - x8

3. PCIe 4.0 x16_3 - x16 x16

4. PCIe 4.0 x16_4 - - x8*

* When the M.2_2 socket on board is operating in PCIe mode, PCIe 4.0 x16_4 will run at x4 mode.
