Asus ROG Zenith II Extreme [27/112] Chapter 1

ROG ZENITH II EXTREME

1-11

Chapter 1

5. BIOS Switch button

This motherboard comes with two BIOS chips. Press the BIOS Switch button to switch

BIOS and load different BIOS settings.

The nearby BIOS_LEDs indicate which BIOS is currently selected.
