10
E
Connecting the Power Cord
Caution
• Useonlythepowercordsuppliedwiththemonitor.
1. Turn off the main power switch.
2. Plug the power cord (supplied) into the AC input terminal.
3. Plug the power cord (supplied) into the AC power outlet.
AC input terminal
1
Main power switch
Power cord (Supplied)
For power
outlet
2
3
Preparing the Remote Control Unit
Installing the batteries
1. Press the cover gently and slide it in the direction of the
arrow.
2. See the instructions in the compartment and put in the
batteries(R-6(“AA”size)x2)(suppliedwiththePN-ZR01
(optional))withtheirplus(+)andminus(-)sidesoriented
correctly.
3. Close the cover.
TIPS
• Whenthebatteriesbecomeexhaustedreplacethemwith
new (commercially available) batteries.
• Thesuppliedbatteries(R-6(“AA”size)x2)maybecome
exhausted quickly depending on how they are stored.
• Ifyouwillnotbeusingtheremotecontrolforalongtime,
remove the batteries.
• Usemanganeseoralkalinebatteriesonly.
Remote control operation range
TheoperationrangeofthePN-ZR01(optional)remotecontrol
unit is approx. 23 feet (7 m) when aimed directly at the remote
controlsensorbox.Whenusedatanangleofapprox10°from
the center to the top/bottom/right/left of the remote control
sensor, use it within a distance of approx 16.4 feet (5 m).
Remote control
sensor
10º10º
16.4 feet
(5 m)
16.4 feet
(5 m)
23.0 feet
(7 m)
23.0 feet
(7 m)
TIPS
• Donotexposetheremotecontrolunittoshockbydropping
or stepping on it. This could lead to a malfunction.
• Donotexposetheremotecontrolunittoliquids,anddonot
place it in an area with high humidity.
• Theremotecontrolunitmaynotworkproperlyiftheremote
control sensor is under direct sunlight or strong lighting.
• Objectsbetweentheremotecontrolunitandtheremote
control sensor may prevent proper operation.
• Replacethebatterieswhentheyrunlowasthismay
shorten the remote control’s operation range.
• Ifauorescentlightisilluminatedneartheremotecontrol
unit, it may interfere with proper operation.
• Donotuseitwiththeremotecontrolofotherequipment
such as air conditioner, stereo components, etc.
• AdjusttheangleofthePN-ZR01(optional)remotecontrol
sensor and have it face the area where operation with the
remote control unit will take place.
