6
E
MOUNTING PRECAUTIONS
• Thisproductisforuseindoors.
• Sincethemonitorisheavy,consultyourdealerbefore
installing, removing or moving the monitor.
• Wheninstalling,removingormovingthemonitor,ensure
that this is carried out by at least 2 people.
• AmountingbracketcompliantwithVESAspecications
is required. Do not use any screw holes other than VESA
holes for installation.
• Whenmovingthemonitor,besuretoholditwitheither
both handles or the 4 corners on the bottom of the unit. Do
not hold the LCD panel. This may cause product damage,
failure, or injury.
• Installthemonitorwiththesurfaceperpendiculartoalevel
surface. If necessary, the monitor may be tilted up to 20
degrees upward or downward.
• Whenperforminganinstallationwherethemonitoris
stacked, please install it such that load is not placed on the
monitor frame.
• Mountingthemonitoronthewallrequiresspecialexpertise
and the work must be performed by an authorized SHARP
dealer. You should never attempt to perform any of this
work yourself. Our company will bear no responsibility
for accidents or injuries caused by improper mounting or
mishandling.
• Thismonitorshouldbeusedatanambienttemperature
between 32°F (0°C) and 104°F (40°C).
• Becarefulofhightemperaturesinthesurroundingarea.
Wheninstallingthemonitorinsideahousing,orifthe
ambient temperature may be outside of the range of 32ºF
(0ºC) to 104ºF (40ºC), install a fan or take other measures
to keep the ambient temperature within the required range.
• Temperatureconditionmaychangewhenusingthedisplay
together with the optional equipments recommended by
SHARP. In such cases, please check the temperature
condition specified by the optional equipments.
• Adheretothefollowingwheninstallingthemonitorinits
vertical orientation. Failing to adhere to the following may
cause malfunctions.
- To install in horizontal orientation, rotate the monitor 90
degrees to the right.
- Set the MONITOR on the SETUP menu to PORTRAIT.
(See Operation guide.)
-Besuretosecurethepowercord(supplied)tothecable
clamp attachment below with the supplied cable clamp.
Make sure that the power cord (supplied) does not supply
power to the terminal when being secured and do not
over bend the power cord (supplied).
• Donotblockanyventilationopenings.Ifthetemperature
inside the monitor rises, this could lead to a malfunction.
• Aftermounting,pleasecarefullyensurethemonitoris
secure, and not able to come loose from the wall or mount.
• Donotplacethemonitoronadevicewhichgeneratesheat.
• Besuretouseawall-mountbracketdesignedor
designated for mounting the monitor.
• Thismonitorisdesignedtobeinstalledonaconcretewall
or pillar. Reinforced work might be necessary for some
materials such as plaster / thin plastic board / wood before
starting installation.
This monitor and bracket must be installed on a wall which
can endure at least 4 times or more the weight of the
monitor. Install by the most suitable method for the material
and the structure.
This manual contains instructions regarding connection and installation.
For other instructions, refer to the instruction manuals in the “manual” folder on the included CD-ROM.
Adobe Reader is required in order to view the instruction manuals.
Contents
IMPORTANT INFORMATION ............................................1
DEAR SHARP CUSTOMER ..............................................3
SAFETY PRECAUTIONS ..................................................3
TIPS AND SAFETY INSTRUCTIONS ...............................5
MOUNTING PRECAUTIONS ............................................6
Supplied Components .....................................................7
Connecting Peripheral Equipment .................................7
Multiple monitor connection .........................................8
Preparing the Remote Control Unit ..............................10
Installing the batteries ................................................10
Remote control operation range .................................10
Connecting the Power Cord .........................................10
Binding Cables ...............................................................11
Removing the Handles ..................................................11
Afxing the Protection Covers .....................................11
Turning Power On/Off ....................................................12
Turning on the main power.........................................12
Turning power on/off ..................................................12
Disabling power on/off operations ..............................12
Cable clamp
Power cord (Supplied)
Cable clamp
attachment
