10
APPLICATION ADVICE
Use the appropriate bits #
! only use sharp bits
For drilling in concrete or stone a steady pressure on the
drill is required
When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
Splinterfree drilling in wood $
Dustfree drilling in walls %
Dustfree drilling in ceilings ^
Drilling in tiles without skidding &
For more tips see www.skil.com
MAINTENANCE / SERVICE
Always keep tool and cord clean (especially ventilation
slots H 2)
! disconnect the plug before cleaning
If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skil.com)
ENVIRONMENT
Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol * will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
60745, EN 61000, EN 55014, in accordance with the
provisions of the directives 2004/108/EC, 2006/42/EC,
2011/65/EU
Technical file at: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
¹ÊÁÂÆιÆ¼½ÊÇǾ¼½Æ
ȽʹÌÁÇÆËŵÆ¿Áƽ½ÊÁÆ¿
ÍÊÇȽƓˁ˅ʿ˂ʽ¼¹Ɠ
Ĺ¾ÁÂÿʹ¹¾
ÈÈÊÇιÄ¹Æ¹¿½Ê
02.12.2013
NOISE/VIBRATION
Measured in accordance with EN 60745 the sound
pressure level of this tool is 94 dB(A) and the sound
power level 105 dB(A) (standard deviation: 3 dB), and the
vibration (hand-arm method; uncertainty K = 1.5 m/s²)
when drilling in metal 5.6 m/s²
when impact drilling in concrete 13.7 m/s²
The vibration emission level has been measured in
accordance with a standardised test given in EN 60745; it
may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintained accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns
Perceuse à percussion 6389
INTRODUCTION
Cet outil est conçu pour les travaux de perçage de
percussion dans la brique, le béton et dans la pierre
naturelle ainsi que le perçage dans le bois, le métal, la
céramique et les matières plastiques
Cet outil n’est conçu pour un usage professionnel
Lisez et conservez ce manuel d’instruction 3
CARACTERISTIQUES TECHNIQUES 1
ELEMENTS DE L’OUTIL 2
A Interrupteur de marche/arrêt et réglage de vitesse
B Bouton de blocage de l’interrupteur
C Molette de réglage de la vitesse maximum
D Commutateur pour inverser le sens de rotation
E Commutateur pour sélectionner la fonction de perçage
F Poignée auxiliaire
G Jauge de profondeur
H Fentes de ventilation
SECURITE
INSTRUCTIONS GENERALES DE SECURITE
ATTENTION! Lisez tous les avertissements de
sécurité et toutes les instructions. Ne pas suivre les
avertissements et instructions peut entraîner un choc
électrique, un incendie et/ou de graves blessures sur les
personnes. Conservez tous les avertissements et
toutes les instructions pour pouvoir s’y reporter
ultérieurement. La notion d’”outil électroportatif” dans les
avertissements se rapporte à des outils électriques
raccordés au secteur (avec câble de raccordement) et à
