ensure th at complete surface of footplate rests firmly on the workpiece I ensure that the blade has come to a complete standstill before you lift the tool from the workpiece keep ventilation slots F uncovered Cable clip ria Technical file at SKIL Europe BV PT SEU ENG1 4825 BD Breda NL Marijn van der Hoofden Operations Engineering APPLICATION ADVICE Olaf Dijkgraaf Approval Manager SKIL Europe BV 4825 BD Breda NL Use the appropriate saw blades I tool accepts most commonly available T shank and U shank blades When cutting metals lubricate saw blade regularly with oil For an accurate straight cut guide tool with footplate along the edge of a straight piece of wood Pre drill a hole before making cut outs Splinter free cutting cover cutting line with several layers of wide tape before cutting always face the good side of the workpiece down Formoretipsseewww skil com 14 01 2014 NOISE VIBRATION Measured in accordance with EN 60745 the sound pressure level of this tool is 96 dB A and the sound power level 107 dB A standard deviation 3 dB and the vibration hand arm method uncertainty K 1 5 m s2 when cutting wood 5 6 m s2 when cutting metal 3 0 m s2 The vibration emission level has been measured in accordance with a standardised test given in EN 60745 it may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned using the tool for different applications or with different or poorly maintained accessories may significantly increase the exposure level the times when the tool is switched off or when it is running but not actually doing the job may significantly reduce the exposure level I protect yourself against the effects of vibration by maintaining the tool and Its accessories keeping your hands warm and organizing your work patterns MAINTENANCE SERVICE This tool is not intended for professional use Always keep tool and cord clean especially ventilation slots F I disconnect the plug before cleaning If the tool should fail despite the care taken in manufacturing and testing procedures repair should be carried out by an after sales service centre for SKIL power tools send the tool undismantled together with proof of purchase to your dealer or the nearest SKIL service station addresses as well as the service diagram of the tool are listed on www skil com ENVIRONMENT Scie sauteuse Do not dispose of electric tools accessories and packaging together with household waste material only for EU countries in observance of European Directive 2012 19 EC on waste of electric and electronic equipment and its implementation in accordance with national law electric tools that have reached the end of their life must be collected separately and returned to an environmentally compatible recycling facility symbol will remind you of this when the need for disposing occurs 4381 Cet outil est conçu pour effectuer des découpes et coupes dans le bois les matières plastiques le métal les plaques en céramique et le caoutchouc et est approprié pour des coupes droites et curvilignes avec des angles d onglet jusqu à 45 Cet outil n est conçu pour un usage professionnel Lisez et conservez ce manuel d instruction INTRODUCTION CARACTERISTIQUES TECHNIQUES DECLARATION OF CONFORMITY C ELEMENTS DE L OUTIL We declare under our sole responsibility that the product described under Technical data is in conformity with the following standards or standardization documents EN 60745 EN 61000 EN 55014 in accordance with the provisions of the directives 2004 108 EC 2006 42 EC 2011 65 EU A Interrupteur pour mise en marche arrêt B Bouton de blocage de l interrupteur C Levier de sélection de mode de coupe D Molette de réglage de la vitesse de sciage E Interrupteur de soufflerie de poussières F Fentes de ventilation G Attache câble 10
