Chapter 1. Introduction
5
No. Component Description
1 handle Pull to slide the LCD module out; push to slide it in.
See Opening the Console / Closing the Console, page 19 for
sliding the console in and out.
2 LCD display After sliding the KVM module out, flip up the cover to access
the LCD monitor by pressing the Handle, see handle, page 5.
3 exit / light
pushbutton
Press the exit / light pushbutton for two seconds to turn the
LED light on or off (default: on)During the LCD OSD mode,
this pushbutton has more functions, refer to The LCD Buttons
on page 22 for more details.
4 LED illumination
light
Illuminates the keyboard and touchpad to allow visibility in
low-light conditions.
5 port selection
pushbutton /
LEDs (8 for
CL3108, 16 for
CL3116)
Press the port pushbuttons to bring the KVM focus to the
computer attached to the corresponding port.
An orange ON LINE LED lights to indicate that the com-
puter attached to its corresponding port is up and running.
An orange ON LINE LED flashes to indicate that the corre-
sponding port is being used for cascading to another
switch.
A green Selected LED lights to indicate that the computer
attached to the corresponding port is selected for KVM con-
trol.
6 keyboard Standard 105-key keyboard
7 touchpad Standard mouse touchpad
8 external mouse
port
The USB port is available to connect a USB keyboard or
mouse device for users who prefer to use an external
keyboard and mouse.
9 power LED Lights green to indicate that the unit is receiving power.
10 lock LEDs The Num Lock, Caps Lock, Scroll Lock LEDs are located
here.
11 reset button Located to the right of the Lock LEDs. Press this button in with
a small object to perform a system reset.
12 firmware
upgrade port
The firmware upgrade cable that transfers the firmware
upgrade data from the administrator’s computer to the
CL3108 / CL3116 plugs into this 3.5 mm audio jack.
13 firmware
upgrade switch
During normal operation and while performing a firmware
upgrade, this switch should be in the NORMAL position. If a
firmware upgrade operation does not complete successfully,
this switch is used to perform a firmware upgrade recovery.
See Upgrade Failed, page 56, for details.
14 panel power
button
Push this button to turn the LCD monitor on and off. The
button lights when the LCD monitor is off.
Note: The light indicates that only the monitor is off, not the
attached KVM switch.
