CC2000 User Manual
270
Options
The Options page provides options for customizing the report colors and for
saving report records, as exemplified below:
To customize the report, do the following:
1. Fill in the Keep report records for months field under Maintenance.
2. Adjust the color fields under Chart Color Customization.
3. When you have finished with this page, click Save at the bottom-right of
the panel.
The meanings of each fields are described in the table below:
Default Color tab: Click to return all colors back to their default settings.
Item Description
Maintenance Enter the number of months you would like the system to keep report
records for before deleting.
Chart Color
Customization
Text color: Click the box to bring up a small window and choose the
color you would like to use for the texts displayed within the reports.
Color 1~12: Click the boxes to bring up a small window to choose the
color you would like to use for each key in the charts.
When selecting a color, the test chart at the right will change
accordingly so you can see how your graph will look like.
