Aten CC2000 4.0 [63/371] Re arranging cards

Chapter 4. Dashboard and Basic Operation

Re-arranging Cards

To re-arrange a section of cards, click on the dots and select Move Section Up

or Move Section Down.

To re-arrange a card within a section, click on the card to drag-and-drop it to a

new place.

Viewing Analysis Chart

To see trend charts of a group of monitored equipment/port, click the dots icon

and select Show History. The trend charts appears. For more information

about trend charts, see Viewing Charts of Monitored Equipment, page 153.
