1
Chapter 1
Introduction
Overview
ATEN PE5108 / PE5208/ PE6108 / PE6208 / PE7108 / PE7208 /PE8108 /
PE8208 eco PDUs are intelligent PDUs that contain 8 AC outlets for
convenient and efficient data power usage management, and are available in
various IEC or NEMA socket configurations.
They provide secure, centralized, intelligent power management (power on,
off, cycle) for data center IT equipment (servers, storage systems, KVM
switches, network devices, serial data devices, etc.), as well as the ability to
monitor the center's environment conditions via sensors*. The basic
characteristics of each model are shown in the table on page 3.
ATEN eco PDUs offer remote power control combined with real-time power
measurement, allowing users to control and monitor the power status of all
devices powered by the PDUs, either at the PDU device or outlet level, from
practically any location via a TCP/IP connection.
The power status of each outlet can be set individually, allowing users to switch
each device on/off. The eco PDU also offers comprehensive power analysis
reports that can be separated by departments and/or locations, providing
precise measurements of the current, voltage, power, and watt-hour in real
time.
Installation and operation is fast and easy: as simple as plugging cables into
their appropriate ports and configuring on a user-friendly web browserfor
intuitive management. Since the eco PDU firmware is upgradeable over a
network, users can keep the PDUs updated with the latest functionality
improvements by downloading updates from their product pages, as they
become available.
ATEN eco PDU supports any 3rd-party SNMP v3 manager software and
ATEN eco DC (eco PDU manager web GUI). ATEN eco DC provides you
with an easy method for managing multiple devices, offering an intuitive and
user-friendly graphical user interface that allows you to configure a PDU
device and monitor power status of the equipment connected.
This series of ATEN eco PDUs have a circuit breaker alert that can sound an
alarm and send SNMP trap or e-mail alerts when a trip occurs. This feature
