31
Chapter 4
Browser Operation
Logging In
The eco PDU can be accessed via a supported Internet browser from any
platform.
Note: Browsers must support TLS 1.2.
To access the eco PDU do the following:
1. Open your browser and specify the IP address of the eco PDU you want to
access in the browser's URL location bar.
Note: You can get the IP address from the eco PDU administrator, or see
IP Address Determination, page 73, for information about setting it
up yourself.
2. If a security alert dialog box appears, accept the certificate—it can be
trusted. The Login page appears:
3. Provide a valid username and password (set by the eco PDU
administrator), and select your language. (Options are: English [default];
Traditional Chinese; Simplified Chinese; Japanese; German; Italian;
Spanish; French).
4. Click Login to bring up the browser main page.
