Руководство пользователя Страница: 46

Aten PE6108 [46/94] Energy

eco PDU PE Series User Manual

Energy

Connections

When you log in to the eco PDU, the interface opens with its default selection

of the Energy tab; and the Connections menu. The contents of the PDU Status

and Outlet Status sections are displayed in the main panel.

Note: Only enabled eco PDU models will display the Outlet Status submenu

section. Other models provide only PDU Status monitoring. See PE

Series eco PDU Comparison Chart, page 3, for which models support

PDU and Outlet Status or PDU Status only monitoring.
