Chapter 4. Browser Operation

When you have finished making your configuration settings, click Save.

Remote Turn ON

Method

Use the drop-down menu to select one of the choices, below:

Wake on LAN: This is a safe shutdown and restart option. If this is

selected, when an outlet is turned off, the eco PDU first sends a

message to the computer telling it to prepare for a shutdown; it

then waits for the amount time set in the Power Off Delay field to

give the OS time to close down before the computer is powered

down to standby mode.

Likewise, when the outlet is turned on, the eco PDU waits for the

amount time set in the Power On Delay field, then sends an

Ethernet message to the computer connected to the outlet telling

the computer to turn itself Oon.

Note: For safe shutdown and restart, the computer must be

running Windows (98 or higher), or Linux, and the Safe

Shutdown program (available by download from our website),

must be installed and running on the computer.

System after AC Back: This is a safe shutdown and restart

option. If this is selected, when an outlet is turned off, the eco

PDU first sends a message to the computer telling it to prepare

for a shutdown; it then waits for the amount time set in the Power

Off Delay field to give the OS time to close down before the

computer is powered down.

When the outlet is turned on, the eco PDU waits for the amount

time set in the Power On Delay field, then sends power to the

server. When the server receives the power, it turns itself on.

Note: For safe shutdown and reboot, the computer must be

running Windows (98 or higher), or Linux, and the safe shutdown

program (available by download from our website), must be

installed and running on the computer.

Kill the Power: If this option is selected, the eco PDU waits for the

amount time set in the Power Off Delay field, and then turns the

outlet's power off. Turning the power off performs a cold (non-

safe) shutdown.

MAC Address In order to use either of the safe shutdown and restart methods the

MAC address of the computer connected to the outlet must be

filled in here.

Heading Meaning
